Reinforcement Learning for UAV Path Planning

By Dr Silpaja Chandrasekar, PhDReviewed by Susha Cheriyedath, M.Sc.Jan 12 2024

In a paper published in the journal Scientific Reports, researchers addressed the challenge of autonomous path planning for unmanned aerial vehicles (UAVs) in unfamiliar environments. The study proposed a reinforcement learning-based algorithm utilizing the twin delayed deep deterministic (TD3) strategy, addressing challenges associated with poor consistency and the significant influence of native controllers.

The approach effectively discussed local obstacle avoidance and path planning, exhibiting a high success rate in obstacle-free scenarios and environments with obstacles, as demonstrated through simulations in the gazebo. This research presented a promising solution for enhancing UAVs' autonomous decision-making capabilities in unfamiliar settings.

Related Work

In past studies, advancements in UAV trajectory control have primarily relied on mature methods utilizing global positioning systems (GPS) for self-positioning or real-time optimization with simultaneous localization and mapping (SLAM). Researchers have actively explored employing geographic information systems (GIS) as an integral part of the training environment for deep reinforcement learning (DRL).

This proactive approach aims to mitigate the inconsistency between training and test environments, empowering UAVs to autonomously navigate intricate geometrical spaces with increased efficacy. While some approaches focus on goal-driven exploration through deep reinforcement learning or efficient autonomous path planning in unfamiliar environments, these often require reliance on control algorithms and manual decision-making, leading to potential issues in obstacle avoidance due to controller changes.

RL Framework

The reinforcement learning (RL) agent utilizes an actor-critic model to map environmental information to UAV actions. Each action includes high-level control instructions, and the actor-network, comprising three fully connected layers, outputs a four-dimensional action set. The critic network, consisting of four fully connected layers, evaluates Q-value values using the TD3 strategy for parameter updates. Notably, the RL training network lacks convolutional layers to streamline data preprocessing and fusion, enhancing training speed.

The data preprocessing and fusion module integrates you only look once version 7 (YOLOv7) outputs, UAV light detection and ranging (lidar) data, and sensor data. This module optimizes the RL agent's state information, which is crucial for accelerating training and facilitating adaptability to various robotic platforms.

The RL agent training treats each path-planning step as a Markovian decision-making process. Rewards shape the learning process, including step rewards, collision penalties, and a fixed 100-point reward for reaching the target point directly above. Step rewards encourage faster travel to the target, while the single-step reward evaluates proximity. The collision reward penalizes UAVs for collisions during path planning.

The TD3 algorithm optimizes the actor and critic networks through strategy gradient updates. The framework leverages the bellman equation for autonomous local path planning under continuous motion. The actor generates strategies, and the critic evaluates and refines them, achieving improved path-planning efficacy. The study ensures ethical considerations, obtaining informed consent from all participants. The study's purpose, procedures, risks, and benefits were actively explained to the participants, assuring them of voluntary participation and the right to withdraw. The research did not involve live animals or human participants.

RL Agent for UAVs

This paper presents a simulation environment in a pavilion based on a real aircraft, utilizing random initialization for UAV position and state information during training. The researchers actively conducted two key experiments: the first experiment focused on local path planning without obstacles, lidar, or collision detection, and the second experiment introduced obstacles along with collision rewards. The experiments aim to validate the RL agent's ability to guide UAVs in unfamiliar environments. The researchers actively minimized model uncertainty by implementing randomized initial conditions for the UAV, target point, and obstacles.

The experiments use a monocular camera and lidar, and the training algorithm is implemented on a computer with specified configurations, providing insight into the algorithm's robustness and adaptability. The researchers actively compared parameter configurations in the accessibility experiments, considering factors such as environmental information, reward noise, and action noise.

The results highlight the importance of data preprocessing, showing improved RL agent performance with reduced redundancy in state information. The researchers actively explored altitude interval adjustments and reward noise variations, demonstrating how these factors impact UAV exploration, convergence time, and planning actions in different map zones.

The subsequent experiments introduce obstacles to test the algorithm's path planning integrity. The RL agent, guided by lidar data, achieves successful path planning in both unaugmented and augmented obstacle environments. The study systematically analyzes average Q values, maximum Q values, and convergence times, providing a comprehensive understanding of the algorithm's performance under varying conditions.

The paper concludes with insights into the algorithm's limitations when facing dynamic obstacles. Factors like the single-step planning approach and the nature of real-time planning contribute to reduced success rates in dynamic obstacle environments. Despite these limitations, the algorithm demonstrates effectiveness in scenarios without and with static obstacles, showcasing its potential for autonomous local path planning in specific contexts.

Conclusion

To summarize, this paper presents an autonomous local path planning algorithm for UAVs, leveraging the TD3 algorithm. The algorithm showcases its effectiveness in unfamiliar environments and offers portability through the HWT_OS system. This feature allows seamless integration with diverse UAV devices without modifying their native controllers. Future endeavors focus on enhancing decision speed for improved performance in dynamic obstacle scenarios and expanding the algorithm's applicability to diverse UAV planning contexts.
