In an article recently published in the journal Scientific Reports, researchers proposed a deep reinforcement learning (DRL)-based routing technique for collision-free vehicular ad-hoc network (VANET).
Background
VANETs primarily consist of different entities that are integrated for effective communication among themselves and with other associated services. VANETs are increasingly being used in transportation engineering to mitigate traffic guidance and congestion issues, optimize traffic flow, and augment road safety.
The classic VANET model includes roadside units (RSUs), traffic analyzers (TAs), and on-board units (OBUs). Additionally, VANETs can be classified into three communication models, including vehicle-to-vehicle (V2V) communication, vehicle-to-infrastructure (V2I) communication, and vehicle-to-roadside (V2R) communication.
The RSUs and OBUs facilitate effective communication between vehicles in both V2I and V2V scenarios, and the wireless technology used in VANETs, designated as wireless access in vehicle environment (WAVE), enables communication between RSUs and vehicles.
The WAVE communication system ensures passenger safety by providing real-time vehicle and traffic information updates. However, excessive control overhead and routing complexities are the major challenges in VANETs. Machine learning (ML) models can facilitate the route selection process in VANETs. Specifically, ML techniques can assist RSUs in effectively regulating vehicular mobility and mitigating traffic congestion.
The proposed approach
In this study, researchers proposed an improved deep reinforcement learning (IDRL) approach for routing the vehicle unit (VU) in VANETs by reducing the augmented control overhead. The IDRL routing technique can optimize the routing path and reduce the convergence time simultaneously in the dynamic vehicle density context.
Additionally, the IDRL can effectively predict, analyze, and monitor routing behavior by leveraging transmission capacity and vehicle data. Thus, the transmission delay reduction can be achieved using adjacent vehicles to transport packets through V2I communication. The proposed technique enables RSUs to maintain traffic information on IDRL-used roads to improve the network capacity performance.
The IDRL Routing Protocol: The IDRL model was utilized to predict the variation in vehicle density, which was then extrapolated to forecast vehicular motion on roadways. The proposed technique did not use a predetermined routing protocol, as the route selection was determined dynamically based on the transmission capacity and a high success probability upon reaching the IDRL driver.
The system was trained using the vehicle speed and movement relative to the nearby RSUs traversed by the VU. Additionally, the data was updated dynamically in response to the incoming unit's proximity to the RSU. Wired lines were used to interconnect the RSUs for entry vehicle data transmission within the study coverage area to disseminate information, specifically velocity, and position, to adjacent RSUs concerning the vehicle's arrival.
Determining the vehicle position using the global positioning system (GPS) is often challenging owing to the high velocity of moving vehicles and privacy and security concerns with GPS technology. The proposed DRL-based approach could mitigate the difficulty of locating the vehicle position. Overall, the entire protocol consisted of the route establishment phase (REP), optimal route establishment (ORE), route selection phase, and route selection phase using IDRL.
Experiment evaluation and findings
Researchers evaluated the performance of the proposed method using the Network Simulator (NS-2.35) simulation tool and performed the simulation in an area measuring 1000 m by 1000 m. They performed a comparative analysis of the proposed IDRL technique with existing peer routing techniques, including adaptive ranking-based improved opportunistic routing (ARIOR), adaptive ranking-based energy-efficient opportunistic routing (AREOR), and improved-AREOR (I-AREOR) to evaluate the packet delivery ratio (PDR).
The simulation outcomes were analyzed to evaluate the scalability and resilience of the IDRL model in mitigating the amplified overheads and delivering efficient routing concurrently. The proposed method demonstrated a high level of efficacy in transmitting messages that were safeguarded through the use of V2I communication. In the simulation results, the IDRL routing approach displayed a reduced latency, improved data reliability, and increased PDR compared to currently available routing techniques.
The IDRL routing technique attained a higher PDR compared to other techniques, with an average increase of 5% compared to ARIOR, the second-best technique, which was attributed to the connectivity information retention between units using announcement messages in the IDRL approach.
In the comparative analysis between PDR and vehicles with high and low densities, the proposed method displayed a 6.5% increase in performance compared to the ARIOR method. Other approaches demonstrated instability owing to their dependence on a distributed architecture. Moreover, the comparative analysis of control overhead in VANETs between the IDRL, ARIOR, I-AREOR, and AREOR also showed that the IDRL implementation led to a higher overhead control reduction than the existing methods.
Journal reference:
- Upadhyay, P., Marriboina, V., Goyal, S. J., Kumar, S., M., S., Ibrahim, A., Alhussan, A. A., Khafaga, D. S. (2023). An improved deep reinforcement learning routing technique for collision-free VANET. Scientific Reports, 13(1), 1-12. https://doi.org/10.1038/s41598-023-48956-y, https://www.nature.com/articles/s41598-023-48956-y
