Automation of Structural Health Monitoring for Civil Infrastructures Using AI and ML

By Dr Silpaja Chandrasekar, PhDReviewed by Susha Cheriyedath, M.Sc.Apr 23 2024

In a paper published in the Journal of Imaging, researchers explored the vital role of continuous monitoring in protecting civil infrastructures and extending their lifespan by highlighting image-processing technologies as crucial for structural health monitoring (SHM). They also discussed integrating artificial intelligence (AI) and machine learning (ML) for enhanced SHM automation and accuracy, showcasing the potential of image-centric approaches for civil engineering professionals.

The review covered advancements and challenges in using various imaging modalities, such as satellite imagery and light detection and ranging (LiDAR). The main topics included damage detection, crack identification, and deformation monitoring through image processing.

Advancements in SHM

Past research has advanced the integration of image-processing techniques into SHM, enhancing the ability to assess and maintain infrastructure integrity. Advanced image processing offers a nuanced approach to structural-condition assessment within the context of SHM, which is crucial for safety and longevity. These techniques enable a detailed examination of structural damages and alterations, surpassing conventional sensors' limitations.

Methodologies such as edge detection and texture analysis facilitate early defect detection by providing non-destructive evaluations and empowering informed decision-making regarding industry maintenance and repair strategies. Integrating AI further enhances damage detection, introducing automated and efficient evaluation for real-time anomaly identification.

Image Acquisition Methods

Various methods for image acquisition in SHM offer unique advantages and applications. Drones with high-resolution cameras have revolutionized structural inspections and monitoring by providing versatile and efficient means of capturing detailed imagery of structures, especially in difficult-to-access areas. Engineers and researchers can conduct comprehensive SHM tasks using drone cameras to enable quick and thorough inspections of large areas such as bridges or pipelines.

This approach enhances safety by reducing the need for risky physical access while empowering better decision-making for maintenance and ensuring structural integrity. Additionally, thermography provides real-time assessment insights into potential issues such as delaminations or moisture ingress. This is achieved through a non-destructive and non-contact method by analyzing infrared radiation emitted by the surface of objects.

Moreover, LiDAR technology monitors structural deformations and identifies surface defects like cracks by employing laser light to create detailed three-dimensional representations of structures. Ultrasonic imaging generates detailed images of internal structures using high-frequency sound waves to detect anomalies such as cracks or delamination. Ground-penetrating radar (GPR) assesses subsurface conditions by emitting electromagnetic waves into the structure or ground. It provides cross-sectional views and depth profiling to identify anomalies or changes in moisture content. Satellite technology, like optical imagery and synthetic aperture radar (SAR), offers wide coverage for large-scale monitoring and environmental impact assessment purposes. While each method has distinct advantages, they collectively enhance SHM and evaluation.

Enhancing Structural Health

Image-processing techniques are essential for accurately assessing structural health conditions. They enable data detection, analysis, and interpretation from various imaging sources. These techniques, including edge detection, texture analysis, image registration, and segmentation, aim to enhance image quality and extract relevant structural features.

Edge detection identifies boundaries or discontinuities within images, while texture analysis explores spatial variations in pixel intensities. Image registration aligns images for accurate comparison, and segmentation partitions images into meaningful regions for detailed analysis.

Furthermore, AI, particularly ML and pattern recognition, enhances post-processing by automating classification tasks and deciphering complex structural patterns. These image-processing and AI approaches contribute to a comprehensive understanding of structural health, facilitating informed decision-making and proactive maintenance strategies in various applications.

Challenges in Image-Based SHM

Image-based SHM encounters numerous challenges that affect its efficacy and dependability. Interpreting captured images to distinguish between normal variations, environmental effects, and actual structural issues requires advanced analysis techniques and expert judgment. The quality and resolution of images significantly influence the accuracy of damage detection, which is compromised by environmental factors and equipment limitations. Moreover, handling large datasets generated by high-resolution images poses practical challenges. Robust algorithms and computing resources are required for efficient storage, transmission, and processing.

Real-time processing and image-based monitoring require rapid analysis to detect emerging damage or structural changes. Standardizing and validating image-based SHM techniques are crucial for ensuring consistency and reliability across different systems—however, environmental variability, such as lighting and weather conditions, challenges reliable monitoring. Image-based SHM faces challenges when integrating with other sensor-based techniques, such as synchronization and data fusion. Maintaining accuracy and reliability across various systems presents complex hurdles.

Furthermore, the automation of image analysis using ML algorithms requires robust training datasets and continuous improvement efforts to ensure high accuracy and reliability, thereby adding complexity to real-time processing. Deployment challenges, including accessibility and installation in remote areas and cost considerations, complicate the obstacles faced by image-based SHM.

Despite these challenges, continuous advancements in imaging technology, algorithm development, and interdisciplinary collaboration are essential to enhance the capabilities and reliability of image-based SHM and ensure the safety and longevity of critical infrastructure.

Conclusion

In summary, this review covered image-processing-based SHM technologies for civil infrastructures. It explored damage types, image acquisition, processing techniques, and AI's role in SHM. Although crucial, not all types of damage were detectable. Proper image acquisition enhanced data quality, while diverse processing techniques offered rich analysis tools, and hybrid approaches improved accuracy. These technologies are widely used to ensure infrastructure safety and reliability.
