Researchers Pioneer Machine-Learning Approach to Enhance Control of Robots in Dynamic Environments

MIT and Stanford University researchers have devised a new machine-learning approach that could be used to control a robot, such as a drone or autonomous vehicle, more effectively and efficiently in dynamic environments where conditions can change rapidly.

This technique could help an autonomous vehicle learn to compensate for slippery road conditions to avoid going into a skid, allow a robotic free-flyer to tow different objects in space, or enable a drone to closely follow a downhill skier despite being buffeted by strong winds.

The researchers' approach incorporates certain structures from control theory into the process of learning a model in such a way that leads to an effective method of controlling complex dynamics, such as those caused by the impacts of wind on the trajectory of a flying vehicle. One way to think about this structure is as a hint that can help guide how to control a system.

Study: Learning Control-Oriented Dynamical Structure from Data. Image Credit: only_kim / Shutterstock

*Important notice: arXiv publishes preliminary scientific reports that are not peer-reviewed and, therefore, should not be regarded as definitive, used to guide development decisions, or treated as established information in the field of artificial intelligence research.

"The focus of our work is to learn intrinsic structure in the dynamics of the system that can be leveraged to design more effective, stabilizing controllers," says Navid Azizan, the Esther and Harold E. Edgerton Assistant Professor in the MIT Department of Mechanical Engineering and the Institute for Data, Systems, and Society (IDSS), and a member of the Laboratory for Information and Decision Systems (LIDS). "By jointly learning the system's dynamics and these unique control-oriented structures from data, we're able to naturally create controllers that function much more effectively in the real world."

Using this structure in a learned model, the researchers' technique immediately extracts an effective controller from the model, unlike other machine-learning methods that require a controller to be derived or learned separately with additional steps. With this structure, their approach can also learn an effective controller using fewer data than other approaches. This could help their learning-based control system achieve better performance faster in rapidly changing environments.

"This work tries to strike a balance between identifying structure in your system and just learning a model from data," says lead author Spencer M. Richards, a graduate student at Stanford University. "Our approach is inspired by how roboticists use physics to derive simpler models for robots. Physical analysis of these models often yields a useful structure for the purposes of control -; one that you might miss if you just tried to naively fit a model to data. Instead, we try to identify similarly useful structure from data that indicates how to implement your control logic."

Additional authors of the paper are Jean-Jacques Slotine, professor of mechanical engineering and brain and cognitive sciences at MIT, and Marco Pavone, associate professor of aeronautics and astronautics at Stanford. The research will be presented at the International Conference on Machine Learning (ICML).

Learning a controller

Determining the best way to control a robot to accomplish a given task can be a complex problem, even when researchers know how to model everything about the system.

For example, a controller is the logic that enables a drone to follow a desired trajectory. This controller would tell the drone how to adjust its rotor forces to compensate for the effect of winds that can knock it off a stable path to reach its goal.

This drone is a dynamic system -; a physical system that evolves over time. In this case, its position and velocity change as it flies through the environment. Engineers can derive a controller by hand if such a system is simple enough.

Modeling a system by hand intrinsically captures a certain structure based on the physics of the system. For instance, if a robot were modeled manually using differential equations, these would capture the relationship between velocity, acceleration, and force. Acceleration is the rate of change in velocity over time, which is determined by the mass of and forces applied to the robot.

But often, the system is too complex to be precisely modeled by hand. Like how swirling wind pushes a flying vehicle, Aerodynamic effects are notoriously challenging to derive manually, Richards explains. Researchers would instead take measurements of the drone's position, velocity, and rotor speeds over time and use machine learning to fit a model of this dynamical system to the data. But these approaches typically don't learn a control-based structure. This structure is useful in determining how to best set the rotor speeds to direct the drone's motion over time.

Once they have modeled the dynamical system, many existing approaches also use data to learn a separate controller for the system.

"Other approaches that try to learn dynamics and a controller from data as separate entities are a bit detached philosophically from the way we normally do it for simpler systems. Our approach is more reminiscent of deriving models by hand from physics and linking that to control," Richards says.

Identifying structure

The team from MIT and Stanford developed a technique that uses machine learning to learn the dynamics model, but in such a way that the model has some prescribed structure that is useful for controlling the system.

With this structure, they can extract a controller directly from the dynamics model rather than using data to learn an entirely separate model for the controller.

"We found that beyond learning the dynamics, it's also essential to learn the control-oriented structure that supports effective controller design. Our approach of learning state-dependent coefficient factorizations of the dynamics has outperformed the baselines in terms of data efficiency and tracking capability, proving to be successful in efficiently and effectively controlling the system's trajectory," Azizan says.

When they tested this approach, their controller closely followed desired trajectories, outpacing all the baseline methods. The controller extracted from their learned model nearly matched the performance of a ground-truth controller, which is built using the exact dynamics of the system.

"By making simpler assumptions, we got something that actually worked better than other complicated baseline approaches," Richards adds.

The researchers also found that their method was data-efficient, which means it achieved high performance even with few data. For instance, it could effectively model a highly dynamic rotor-driven vehicle using only 100 data points. Methods that used multiple learned components saw their performance drop much faster with smaller datasets.

This efficiency could make their technique especially useful in situations where a drone or robot needs to learn quickly in rapidly changing conditions.

Plus, their general approach could be applied to many types of dynamical systems, from robotic arms to free-flying spacecraft operating in low-gravity environments.

In the future, the researchers are interested in developing more physically interpretable models that would be able to identify very specific information about a dynamical system, Richards says. This could lead to better-performing controllers.

This research is supported, in part, by the NASA University Leadership Initiative and the Natural Sciences and Engineering Research Council of Canada.
